AnHui TianKang Magnetic flap level gauge Safety Integrity Level Certificate SIL2
DOWNLOAD
No. 3U180831.ATKTD67 Technical Construction File no. SIL-TKUHZ-(18)-08
Certificate’s Holder: Anhui Tian Kang (group) Shares Co., Ltd.
No.20 South Renhe Road, Tianchang City, Anhui Province, China
Product: Magnetic Float Liquid Level Gauge
Model(s): UHZ-50 Series
Standard: Has been assessed per the relevant requirements of: IEC 61508:2010 Parts 1-2
And meets requirements providing a level of integrity to: Systematic Capability: SC 2 (SIL2 Capable)
Random Capability: Type A Element, SIL2 Capable @HFT=0, Route 1H
PFDAVG and Architecture Constraints must be verified each application
Safety Function:
The UHZ-50 will measure liquid level within the stated safety accuracy in the effective measurement range.
* Is suitable to be safety function according to the description and the configuration defined in Annex I
