Product description: Pressure gauge Mounting On block and bleed 2 valve 1/2" NPT is widely used in various industrial production processes and is often used to measure the pressure of various fluids, gases or steam. AnHui
INQUIRY

Pressure gauge Mounting On block and bleed 2 valve 1/2" NPT is widely used in various industrial production processes and is often used to measure the pressure of various fluids, gases or steam. AnHui TianKang Pressure Gauge,Especially in the production process, when the pressure needs to be measured on the fluid medium to ensure quality accuracy and stability, the application of the two-valve manifold is even more important. The two-valve group consists of two switch valves, one of which is a stop valve (switch or conduction), and the other is a discharge (usually dirt, water, gas). The two-valve group is used at the front end of the pressure gauge.
Pressure gauge Mounting On block and bleed 2 valve 1/2" NPT Structure

The pressure gauge two-valve group is mainly composed of a pressure gauge, an inlet valve and an outlet valve. Among them, the inlet valve and the outlet valve are connected to the measured pressure source and the measured pressure port respectively. The pressure gauge is located between the inlet valve and the outlet valve, with pipes connecting them both. The inlet valve is generally a straight-through ball valve, and the outlet valve is a tilting plunger ball valve.

Pressure gauge Mounting On block and bleed

Pressure gauge Mounting On block and bleed 2 valve 1/2" NPT Working principle
The pressure gauge two-valve group is mainly used to measure the pressure between the pressure source and the measured pressure port. Here's how it works:
1. Pressure source end: The inlet valve opens and flows directly to the pressure source to be measured. At this time, most of the pressure drops on the inlet valve, and the pressure after the inlet valve remains basically unchanged.
2. Pressure gauge end: The pressure pipe of the pressure gauge is connected between the inlet valve and the outlet valve. At this time, the pressure received by the pressure gauge is part of the pressure source flowing into the inlet valve.
3. The measured pressure port end: The outlet valve is basically closed, causing the pressure from the measured pressure port to be transmitted along the pipeline to the gate plate of the outlet valve. At this time, the inclined plunger of the outlet valve moves the gate plate away. After the pressure passes through the outlet valve, into the discharge pipe.
4. Measuring pressure: In the above process, the pressure received by the pressure gauge is the pressure of the entire system, and its value is the pressure difference between the measured pressure source and the measured pressure port, which is displayed through the pressure gauge to achieve the measured pressure. the goal of.
Generally speaking, Pressure gauge Mounting On block and bleed 2 valve 1/2" NPT is a pressure measurement tool with reliable performance, easy installation and operation, and can meet the needs of different industrial fields.
